Text:/ Derek Powell

IMPLICATIONS AT THE COALFACE

Security isn’t just a matter for manufacturers. It needs to be understood by everyone in the industry, from sales staff to designers and installers.

Firstly, if you can’t understand the customer’s IT security standards then you may be unable to demonstrate that your product is capable of meeting these and you may not be allowed to connect to the network. At best this will compromise some of the features you promised and at worst, the system may not operate at all. But there’s more:

It is not enough to supply your clients with equipment that has the right network security features. According to Paul Zielie, in some jurisdictions an installer may also have a legal responsibility to ensure that the system is configured to operate in a secure manner. In his presentations, Paul explains that the concept of due care may be used as a test of liability for negligence, should the worst happen.

“It is expected that a ‘reasonable and prudent person’ would secure their network in a business,” he notes. “If it can be shown that the consultant or integrator organisation secures their own network then they must show the same care to their customer they exercise themselves.”

Proving due care involves showing that the necessary steps have been taken to help protect the organisation, its resources, and employees. Reviewing organisational security policies and specifying products and configurations which meet those policies show due care.

This is a tricky area and you shouldn’t rely on this as definitive legal advice in Australia.  Nonetheless it is clear from what we have seen that we all need to be concerned with network security issues.

STEPS TO TAKE

All least the steps required to implement proper IT security are easy to understand. That’s because they largely mirror the best practice stages in any AV design and installation. There are five vital steps in each and every installation that requires equipment to be connected to your client’s network.

Step 1 — Needs Analysis: Once it’s established that equipment you will be supplying and installing has to be connected to the customer’s network, then you must ask for (and understand) the organisation’s IT security policies and requirements.

Step 2 — Design & Document: Design your installation using equipment that meet those IT security requirements. Prepare separate IT security documentation that show how their security requirements are met. This documentation is vital and will be used for the next steps. We’ll see more about how you write this later.

Step 3 — Sign-Off: Identify the responsible parties and get sign-off on the security documentation.

Step 4 — Configure: Working with the customer’s network administrators, confirm all network access is correctly configured and appropriate permissions set. Ensure all equipment passwords and software configuration are accurately recorded on the security documentation.

Step 5 — Handover: Deliver the completed IT security documentation to your client.

And it’s that simple! Well, it would be nice if it were. Let’s take a closer look at each stage to see what can go wrong – and how to get it right.

NEEDS ANALYSIS NEED TO KNOW

Too often in the past, audiovisual consultants and designers have ignored this step altogether. Frequently, they were secretly concerned the system mightn’t be able to be secured and if this wasn’t discovered until ‘too late’ the client’s IT people would be forced to simply make an exception and allow connection to the network anyway.

Indeed, this strategy used to work. Not anymore. As we discussed earlier, the cost of IT security failures has become so high that IT managers now certainly have the power to stop any installation in its tracks, forcing a re-design that can cost your business dearly.

The first step is to engage with your client’s IT department. You need to find out what their security policies are, so you can then show how your equipment will conform to those policies (or what you can do if that’s not possible). Many integrators dodge this step because they have no idea what sort of information they are going to get or what it may mean. So it’s time for a quick cheat sheet on the kinds of issues that will arise. At the end of the article I’ll give you a handful of web references to some really good guides to how this all works, which you should read. But first let’s set up the basic framework so you can understand the common security requirements.

Most security requirements you’ll have to meet fit into one of only three straightforward categories. If you can recognise which is which, you will be well on your way to understanding what they are and solving them. Think of these three categories as who can get onto the network; where they can go in the network; and what they can see.

ACCESS CONTROL: WHO’S WHO

It’s tempting to say this is all about passwords, and passwords are crucial, but you need to understand that there’s more to Access Control than just changing the default system password. Most IT organisations use the combination of Usernames and Passwords for these functions:

• To verify that the user is who they say they are (Authentication)
• To verify that the user has permission to do the task (Authorisation)
• To keep a record of who accessed the system (Accounting)

The provide Access Control, part of the IT security policy will be designed to make sure only certain people can get into the deep menus and make changes to the system that’s connected to their network.  It also wants to make sure that if any changes are made, those changes are recorded in a log along with the identity of the user who made them.

To perform these three functions, either your AV device must be able to store lists of users, their passwords and records of what they did when logged in; or the AV system must be able to communicate on the network to an established directory that holds the records about everyone’s usernames, passwords and permissions (this is often called an LDAP or Windows Active Directory server).

UNDERSTANDING VLANS

In a network, every device is connected to every other device. But there are ways and means of making sure that commands from AV control systems (for example) can only reach devices like projectors that need to be controlled. We don’t want commands entered in via a touchpanel to reach secure places like where financial records are stored.

Sometimes this means building a physically separate network for the AV systems so that rogue operators don’t have a physical connecting cable to get to the secure parts of the network. However, there are better ways of separating things out. Instead of building a physically separate local area network (LAN), the network administrators can set rules in the various network routers that create separate islands in the network that are virtually separate from the rest of the LAN. These are called VLANs. VLANs are a good way of keeping AV devices on their own virtual network but still letting the right people or devices get through when needed.

An access control list (ACL) can be used to either allow or prevent devices on separate VLANs from getting through to each other. An ACL lists the devices from which a router will allow messages to pass. If a control system, say, wants to get through to a computer on another VLAN, it has to be on the list before its traffic is allowed through. ACLs are set up by the network administrators, but as part of the AV security documentation, you may be asked to create a list of which devices need to talk to each other to build that list.

Devices like computers, control systems and so on have various ways of communicating with each other across a network. These different communications connections are called ‘services’. Services are referred to by a variety of acronyms like HTTP, HTTPS, TELNET, SSH and so on. Some services are more secure than others. A device may have many services activated but some may not be needed in the particular situation. The network security part of your client’s IT security requirements might specify that if your particular installation doesn’t need a certain service, then it must be switched off. It is a bit of a stretch, but you can think of this as being like a projector that can be controlled by RS-232, IP or IR. If you are only ever going to use RS-232 control, you might want to disable the IR functions so that someone who gets hold of an IR remote doesn’t wreak havoc by taking control.

ENCRYPTION: SPEAK IN CODE

The third of our categories in the security requirements is encryption. If someone taps into the communications between AV devices, can they see what is happening or is the communication in code so that no one can understand it. For the AV world, this can refer to encryption of audio or encrypted videoconference signals so that eavesdropping on sensitive conversations is impossible. However, it may also be a requirement that network communications between devices (such as when passwords are exchanged) be encrypted so that intruders can’t steal passwords.

DESIGN & DOCUMENT

Documenting the network security aspects of AV systems is one area that causes confusion. The documentation should be based on the Client’s stated policies and requirements and many network administrators will have a template form for you to complete.

If you want to get a feel for best practice in this area, download the example template that Harman has made available (web reference below). This has been put together by Paul Zielie as a companion to his excellent workbooks that cover ‘Security for Networked AV’ (also accessible through the references at the end of this article). As a minimum, look carefully at the ‘Device Inventory’ and ‘Ports & Protocols’ sheets in this Excel workbook. In the header Paul gives helpful instructions and examples for how these should be filled out.

Most major manufacturers (certainly AMX, Crestron and Extron) have already documented the information you will need for each of their products, however this isn’t usually included in the product’s specification sheets — you’ll need to look deeper into the user manuals and elsewhere.  AMX publishes a ‘Network Administrator’s Guide’ with very comprehensive data and a clear discussion of security aspects. The Crestron equivalent is the ‘Crestron Secure Deployment Guide’ which is similarly detailed. For Extron products, the ‘Extron Control System Design Guide’ brings together most of the information you will need for good documentation.

The best advice, if you are uncertain, is to first engage with your client’s network administrators to find out their expectations. Find out if they have a standard form to complete or if there are any other processes to follow to allow connection to their network. Then, if you need further advice, contact your equipment suppliers. I have already noted that AMX (and Harman) are very much on the front foot in assisting integrators and users with information and advice, and I found both Crestron and Extron are also very aware of IP security issues.

Extron’s Director of Product Marketing, Joe da Silva, emphasised the importance of access control at every level, but noted that simply changing the default passwords in equipment as it is installed is a crucial and often overlooked step.  “I think there’s a lot of work to do to educate our colleagues in this industry to understand the amount of responsibility and the amount of integrity with which they need to approach IT Security.  I think that’s a big task for our industry,” he told me.

“We take IT security very seriously at Extron and it’s always top of mind,” he said. Joe also confirmed that Extron made it a priority to answer customer concerns about security, creating a special engineering team to handle these queries. “When a question comes up about protocols or if there are security questions about our product this group is brought in and we respond to those questions quickly and efficiently,” he stressed.

So assistance is readily available from suppliers. The message from the industry is “just ask and we are here to help”.

DOCUMENTATION SIGN OFF

Savvy professionals are already aware of the importance of having their designs signed off before commencing the installation but with the security aspects there’s one more complication. Who has (or should have) input to the approval process? Make sure you identify all the stakeholders. As well as the network administrators, seek input from the operational staff and the physical security group (if there is one). Finally, don’t forget to check if there are any external standards that must be met. Government and large corporate clients often have to meet external IT security standards (and pass audits).

CONFIGURATION

As we saw earlier, it is not enough to simply install equipment that can be made secure. If you install equipment to a network without ensuring that it is securely configured, you may still be held liable for subsequent problems. This is where the documentation (and the spreadsheets) we spoke about earlier come into their own.

You need to ensure all the settings and passwords are correct on your equipment (and recorded on the spreadsheet) and then have the client’s network administrators do their part to properly configure the network and set all necessary permissions and access control lists. This isn’t an optional step, because most likely nothing will work if it isn’t done. Do arrange a time in advance with the network people — sometimes changes can only be made according to a weekly schedule and not just whenever you happen to ask!

HANDOVER

Hurray! We’re done! So don’t forget to hand over the security documentation (and keep a copy for yourself in case equipment changes are necessary).

EPILOGUE

As professionals we have adjusted to the analogue sunset, dealt with the digital transition and made sense of the hurdles in HDCP, so I am confident IT security will eventually be just another set of lessons learned. Possibly the hardest part is figuring out how to properly charge for all our time and effort in those extra steps we’ve just discussed.

Perhaps that’s a topic for another day.
